Complete Guide to Next.js File Upload: S3/Qiniu Cloud Presigned URL Direct Upload

A user clicks the “Upload Avatar” button and selects a 10MB photo. The progress bar reaches 30% and freezes. 40 seconds later, the browser throws an error: “Request Entity Too Large.”

Staring at Vercel’s deployment logs, I see that familiar “4MB body size limit” error for the third time, cursing Next.js’s API limitations in my head. Honestly, when I first started building file upload features, I thought writing a simple API Route would do the trick. Reality taught me otherwise: users upload increasingly larger files, server memory gets tight, and upload speeds are so slow you want to smash your computer.

Later I discovered a more elegant solution—presigned URL direct upload to cloud storage. User files no longer go through your server but upload directly to S3 or Qiniu Cloud. Speed increased 3x, server pressure dropped to zero, and the file size limit jumped from 4MB to 5GB.

This article will walk you through implementing this solution step by step. You’ll learn how to configure S3 and Qiniu Cloud, generate presigned URLs, handle upload progress, optimize images, and avoid all the pitfalls I encountered. All code examples are production-ready and work out of the box.

Why Choose Presigned URL Direct Upload?

Three Fatal Problems with Traditional Approach

Let me first show you how traditional file upload works: user selects file → uploads to your Next.js server → server forwards to cloud storage. Sounds reasonable, but in practice, it’s full of problems.

Problem 1: Next.js API Has Hard Limits

Vultr - 高性能 NVMe 云服务器，32 个全球节点可选，支持一键部署 Docker

查看定价 →推广

Next.js’s App Router has strict request body size limits—4MB by default. Edge Runtime is even harsher at just 1MB. You might think about adjusting configs to loosen the limit, but platforms like Vercel won’t let you. Even if you could increase it to 10MB or 50MB, users uploading HD videos would still hit the wall.

Problem 2: Server Can’t Handle the Load

What does files going through the server mean? Double memory consumption. When a user uploads a 100MB file, your server first receives that 100MB (consuming memory), then forwards it to S3 (consuming more memory). 10 users uploading simultaneously? Your 2GB instance crashes.

I once built a photo community where during peak hours the server CPU spiked to 90%, all spent on file forwarding. After switching to direct upload, CPU usage dropped straight to 15%. This isn’t optimization—it’s a qualitative leap.

Problem 3: Slow Speed, Poor Experience

Files going through the server means taking an extra detour. User in Shenzhen, your server in Silicon Valley, S3 in Singapore—the upload path becomes: Shenzhen → Silicon Valley → Singapore. With presigned URL direct upload? Shenzhen → Singapore. Path shortened by half, speed naturally faster.

How Do Presigned URLs Work?

Simply put, presigned URLs are “temporary passes” given by cloud storage services. Here’s the flow:

1. User clicks upload, your frontend requests Next.js server: “I want to upload a file”
2. Server contacts S3: “Generate a 60-second valid upload link for me”
3. S3 returns an encrypted URL like https://xxx.s3.amazonaws.com/file.jpg?signature=xxxx&expires=1234567890
4. Frontend takes this URL and directly PUTs the file to S3, completely bypassing your server
5. Upload completes, S3 returns the final file address

The beauty of this “temporary pass”: time-limited (auto-expires after 60s), minimum permissions (can only upload this one file), no exposed keys (frontend can’t access your AWS Secret Key).

Technical Advantages Comparison

Let me list the differences between the two approaches for clarity:

AWS’s official documentation clearly states that single presigned URL uploads support up to 5GB files. For larger files, use Multipart Upload, which theoretically has no limit.

S3 vs Qiniu Cloud: How to Choose?

Technical principles covered, now facing a practical question: use S3 or Qiniu Cloud? I’ve used both, let me analyze their characteristics.

Pricing: Annual Packages vs Pay-As-You-Go

Qiniu Cloud follows an “annual package” approach. Free tier is generous: 10GB storage + 10GB download traffic monthly, enough for personal projects. Overage uses tiered pricing: storage ¥0.148/GB/month, CDN traffic ¥0.29/GB.

Let’s calculate: your app has 1000 users, each uploads 10 images (average 2MB), totaling 20GB storage. Monthly download traffic assumes 100GB. Qiniu Cloud cost:

• Storage: (20GB-10GB free) × ¥0.148 = ¥1.48
• Traffic: (100GB-10GB free) × ¥0.29 = ¥26.1
• Monthly total: ¥27.58

AWS S3 is pure pay-as-you-go. No free tier (new accounts get some free first year), but more flexible pricing. For us-east-1 region: storage $0.023/GB/month, traffic $0.09/GB.

Same scenario, S3 cost:

• Storage: 20GB × $0.023 × 7 (CNY exchange rate) ≈ ¥3.22
• Traffic: 100GB × $0.09 × 7 ≈ ¥63
• Monthly total: ¥66.22

At first glance S3 costs double, but don’t forget S3 traffic can be optimized through CloudFront CDN, and global node access is more balanced.

Domestic Access Speed: This Matters

If your users are mainly in China, Qiniu Cloud’s CDN nodes are more densely distributed with noticeably faster access. I’ve tested: Shenzhen users accessing Qiniu images average 30-50ms latency; accessing AWS S3 (even Tokyo nodes) takes 120-180ms.

What’s the difference? Qiniu Cloud has ICP filing in China and can use domestic CDN nodes; AWS S3 nodes are mostly overseas, data crosses borders. If you target overseas markets, S3 has clear advantages; focus on China, Qiniu is more practical.

Documentation and Ecosystem: English vs Chinese

AWS documentation is comprehensive but all in English with lots of terminology—beginners can get confused. Qiniu Cloud’s Chinese documentation is very clear with abundant code examples.

Ecosystem-wise, S3 wins hands down. Next.js, Vercel, various open-source libraries treat S3 as a first-class citizen. Qiniu Cloud’s community is relatively small—you might need to figure things out yourself when encountering issues.

My Selection Advice

Decision tree:

• Choose S3 if you:

  • Build international products with global users
  • Already use other AWS services (Lambda, RDS, etc.)
  • Need powerful features (like using Lambda to auto-process uploaded images)
  • Have sufficient budget, value ecosystem and stability

• Choose Qiniu Cloud if you:

  • 90% of users are in China
  • Startup team with limited budget, want to save where possible
  • Need Chinese technical support, don’t want to wade through English docs
  • Have high CDN acceleration requirements

My own projects? Mainly targeting China market uses Qiniu Cloud, with overseas users uses S3. Can configure both without conflict.

S3 Presigned URL Implementation (App Router)

Let’s cut to the chase with code. I’ll break down the entire process into 4 steps: environment setup, server-side API, client-side component, and image processing.

Step 1: Environment Setup

Install two official AWS packages:

npm install @aws-sdk/client-s3 @aws-sdk/s3-request-presigner

Then add your AWS credentials in .env.local:

AWS_REGION=ap-southeast-1  # Choose region closest to your users
AWS_ACCESS_KEY_ID=YourAccessKey
AWS_SECRET_ACCESS_KEY=YourSecretKey
AWS_S3_BUCKET_NAME=my-app-uploads

Where do these values come from? Log into AWS console, create an IAM user with minimum permissions (only upload to specified Bucket), note down Access Key. Create Bucket in S3 console, select a region.

Don’t forget CORS configuration! Enter S3 Bucket settings, add CORS rule:

[
  {
    "AllowedHeaders": ["*"],
    "AllowedMethods": ["PUT", "POST"],
    "AllowedOrigins": ["http://localhost:3000", "https://yourdomain.com"],
    "ExposeHeaders": ["ETag"]
  }
]

Without this, browser will report CORS errors. How do I know? I’ve been there.

Step 2: Server-Side Presigned URL Generation

Create app/api/upload/route.ts:

import { S3Client, PutObjectCommand } from '@aws-sdk/client-s3';
import { getSignedUrl } from '@aws-sdk/s3-request-presigner';
import { NextRequest, NextResponse } from 'next/server';

const s3Client = new S3Client({
  region: process.env.AWS_REGION!,
  credentials: {
    accessKeyId: process.env.AWS_ACCESS_KEY_ID!,
    secretAccessKey: process.env.AWS_SECRET_ACCESS_KEY!,
  },
});

export async function POST(request: NextRequest) {
  try {
    const { fileName, fileType } = await request.json();

    // Security check: only allow images
    if (!fileType.startsWith('image/')) {
      return NextResponse.json(
        { error: 'Only image formats supported' },
        { status: 400 }
      );
    }

    // Generate unique filename to avoid overwriting
    const key = `uploads/${Date.now()}-${fileName}`;

    const command = new PutObjectCommand({
      Bucket: process.env.AWS_S3_BUCKET_NAME!,
      Key: key,
      ContentType: fileType,
    });

    // Generate 60-second valid presigned URL
    const uploadUrl = await getSignedUrl(s3Client, command, {
      expiresIn: 60,
    });

    // Return upload URL and final file address
    const fileUrl = `https://${process.env.AWS_S3_BUCKET_NAME}.s3.${process.env.AWS_REGION}.amazonaws.com/${key}`;

    return NextResponse.json({ uploadUrl, fileUrl });
  } catch (error) {
    console.error('Failed to generate presigned URL:', error);
    return NextResponse.json(
      { error: 'Server error' },
      { status: 500 }
    );
  }
}

Core logic of this code:

1. Receive filename and type
2. Check if it’s an image (prevent uploading executable files)
3. Generate unique key using timestamp + original filename
4. Call getSignedUrl to generate temporary URL
5. Return upload URL and final access address

Note expiresIn: 60—after 60 seconds this URL expires. You can change it to 300 (5 minutes), but don’t recommend too long, security first.

Step 3: Client-Side Upload Component

Create components/FileUpload.tsx:

Railway - 现代化的部署平台，告别繁琐运维，让代码分钟级上线

立即开始 →推广

'use client';

import { useState } from 'react';

export default function FileUpload() {
  const [file, setFile] = useState<File | null>(null);
  const [uploading, setUploading] = useState(false);
  const [progress, setProgress] = useState(0);
  const [fileUrl, setFileUrl] = useState('');

  const handleUpload = async () => {
    if (!file) return;

    setUploading(true);
    setProgress(0);

    try {
      // 1. Request presigned URL from server
      const response = await fetch('/api/upload', {
        method: 'POST',
        headers: { 'Content-Type': 'application/json' },
        body: JSON.stringify({
          fileName: file.name,
          fileType: file.type,
        }),
      });

      const { uploadUrl, fileUrl: finalUrl } = await response.json();

      // 2. Upload with XMLHttpRequest to monitor progress
      await new Promise((resolve, reject) => {
        const xhr = new XMLHttpRequest();

        xhr.upload.addEventListener('progress', (e) => {
          if (e.lengthComputable) {
            const percent = Math.round((e.loaded / e.total) * 100);
            setProgress(percent);
          }
        });

        xhr.addEventListener('load', () => {
          if (xhr.status === 200) {
            resolve(xhr.response);
          } else {
            reject(new Error('Upload failed'));
          }
        });

        xhr.addEventListener('error', () => reject(new Error('Network error')));

        xhr.open('PUT', uploadUrl);
        xhr.setRequestHeader('Content-Type', file.type);
        xhr.send(file);
      });

      setFileUrl(finalUrl);
      alert('Upload successful!');
    } catch (error) {
      console.error(error);
      alert('Upload failed, please retry');
    } finally {
      setUploading(false);
    }
  };

  return (
    <div className="max-w-md mx-auto p-6">
      <input
        type="file"
        accept="image/*"
        onChange={(e) => setFile(e.files?.[0] || null)}
        className="block w-full text-sm"
      />

      <button
        onClick={handleUpload}
        disabled={!file || uploading}
        className="mt-4 px-4 py-2 bg-blue-600 text-white rounded disabled:opacity-50"
      >
        {uploading ? `Uploading ${progress}%` : 'Start Upload'}
      </button>

      {uploading && (
        <div className="mt-4 w-full bg-gray-200 rounded h-2">
          <div
            className="bg-blue-600 h-2 rounded transition-all"
            style={{ width: `${progress}%` }}
          />
        </div>
      )}

      {fileUrl && (
        <div className="mt-4">
          <p className="text-sm text-gray-600">Upload successful!</p>
          <img src={fileUrl} alt="Uploaded image" className="mt-2 max-w-full" />
        </div>
      )}
    </div>
  );
}

Why use XMLHttpRequest instead of fetch? Because the fetch API doesn’t support monitoring upload progress. I know this API looks old-school, but in this scenario, it’s the best choice.

User experience details:

• Progress bar shows real-time percentage
• Button disabled during upload to prevent duplicate clicks
• Auto-display image preview after upload

Step 4: Image Processing and Optimization

Uploaded images usually need compression. Two approaches:

Approach 1: Client-Side Pre-Compression (I recommend this)

Install a library:

npm install browser-image-compression

Add compression logic before upload:

import imageCompression from 'browser-image-compression';

const handleUpload = async () => {
  if (!file) return;

  // Compress image
  const options = {
    maxSizeMB: 1,          // Maximum 1MB
    maxWidthOrHeight: 1920, // Max width/height 1920px
    useWebWorker: true,     // Use Web Worker, don't block main thread
  };

  const compressedFile = await imageCompression(file, options);

  // Use compressedFile instead of file for upload
  // ...
};

Benefits of this approach? Reduce upload time, save S3 storage costs, lower CDN traffic fees. I’ve tested—a 5MB iPhone photo compresses to just 500KB, with no visible quality difference to the naked eye.

Approach 2: Server-Side Auto-Processing

Use S3’s Lambda triggers. Whenever a file uploads to Bucket, trigger Lambda function to auto-generate thumbnails, compress images, add watermarks, etc. This approach is more powerful but complex to configure, suitable for developers with AWS experience.

Qiniu Cloud Integration Solution

Qiniu Cloud implementation is similar to S3, but the API differs. I’ll quickly go through key steps, focusing on the differences.

Configuring Qiniu Cloud

First register on Qiniu Cloud’s official site, create an object storage bucket. Note these details:

• AccessKey and SecretKey (in Personal Center - Key Management)
• Bucket name
• CDN domain (Qiniu assigns a test domain, production needs your own domain)

Install Qiniu Cloud’s Node.js SDK:

npm install qiniu

Add config to .env.local:

QINIU_ACCESS_KEY=YourAccessKey
QINIU_SECRET_KEY=YourSecretKey
QINIU_BUCKET=YourBucketName
QINIU_DOMAIN=YourCDNDomain

Server-Side Upload Token Generation

Qiniu Cloud doesn’t call it presigned URL, but upload token, though the principle is the same.

Create app/api/qiniu-upload/route.ts:

import qiniu from 'qiniu';
import { NextRequest, NextResponse } from 'next/server';

const mac = new qiniu.auth.digest.Mac(
  process.env.QINIU_ACCESS_KEY!,
  process.env.QINIU_SECRET_KEY!
);

export async function POST(request: NextRequest) {
  try {
    const { fileName } = await request.json();

    // Generate unique filename
    const key = `uploads/${Date.now()}-${fileName}`;

    const options = {
      scope: `${process.env.QINIU_BUCKET}:${key}`,
      expires: 3600, // Token valid for 1 hour
      returnBody: JSON.stringify({
        key: '$(key)',
        hash: '$(etag)',
        url: `https://${process.env.QINIU_DOMAIN}/$(key)`,
      }),
    };

    const putPolicy = new qiniu.rs.PutPolicy(options);
    const uploadToken = putPolicy.uploadToken(mac);

    return NextResponse.json({
      token: uploadToken,
      key: key,
      domain: process.env.QINIU_DOMAIN,
    });
  } catch (error) {
    console.error('Failed to generate Qiniu token:', error);
    return NextResponse.json({ error: 'Server error' }, { status: 500 });
  }
}

Differences from S3:

• S3 returns a complete URL, Qiniu returns a token
• S3 uses 60s expiry, Qiniu commonly uses 3600s (1 hour)
• Qiniu’s returnBody defines the data structure returned after successful upload

Client-Side Upload to Qiniu Cloud

Qiniu Cloud recommends using their official JS SDK, but I prefer using FormData directly—more lightweight.

'use client';

import { useState } from 'react';

export default function QiniuUpload() {
  const [file, setFile] = useState<File | null>(null);
  const [uploading, setUploading] = useState(false);
  const [fileUrl, setFileUrl] = useState('');

  const handleUpload = async () => {
    if (!file) return;

    setUploading(true);

    try {
      // 1. Get upload token
      const response = await fetch('/api/qiniu-upload', {
        method: 'POST',
        headers: { 'Content-Type': 'application/json' },
        body: JSON.stringify({ fileName: file.name }),
      });

      const { token, key, domain } = await response.json();

      // 2. Upload to Qiniu Cloud
      const formData = new FormData();
      formData.append('file', file);
      formData.append('token', token);
      formData.append('key', key);

      const uploadResponse = await fetch('https://upload.qiniup.com', {
        method: 'POST',
        body: formData,
      });

      const result = await uploadResponse.json();
      setFileUrl(`https://${domain}/${result.key}`);
      alert('Upload successful!');
    } catch (error) {
      console.error(error);
      alert('Upload failed');
    } finally {
      setUploading(false);
    }
  };

  return (
    <div className="max-w-md mx-auto p-6">
      <input
        type="file"
        accept="image/*"
        onChange={(e) => setFile(e.files?.[0] || null)}
        className="block w-full text-sm"
      />

      <button
        onClick={handleUpload}
        disabled={!file || uploading}
        className="mt-4 px-4 py-2 bg-green-600 text-white rounded disabled:opacity-50"
      >
        {uploading ? 'Uploading...' : 'Upload to Qiniu'}
      </button>

      {fileUrl && (
        <div className="mt-4">
          <p className="text-sm text-gray-600">Upload successful!</p>
          <img src={fileUrl} alt="Uploaded image" className="mt-2 max-w-full" />
        </div>
      )}
    </div>
  );
}

Qiniu Cloud’s upload endpoint is fixed: https://upload.qiniup.com. If your users are mainly in East China, you can use https://upload-z0.qiniup.com for faster speeds.

Image Processing

Qiniu Cloud’s image processing is way more convenient than S3—no Lambda needed, just add parameters to the URL.

For example, if original image URL is https://xxx.com/image.jpg, to generate a 300px wide thumbnail:

https://xxx.com/image.jpg?imageView2/2/w/300

To compress to under 100KB:

https://xxx.com/image.jpg?imageMogr2/strip/quality/75

This is called data processing (fop). Qiniu Cloud supports dozens of image operations that are powerful when combined. S3 requires Lambda or third-party services for the same functionality—much more hassle.

Code Comparison with S3 Solution

Overall, Qiniu Cloud’s API is more familiar to Chinese developers with clearer documentation and faster onboarding. S3 is more powerful but has a steeper learning curve.

Production Environment Best Practices

Code that runs is one thing, code that runs stably in production is another. Here I’ll share some pitfalls I’ve encountered and corresponding solutions.

Security: Never Leak Keys

The easiest mistake to make: putting AWS Secret Key in frontend code. People actually do this, then receive thousands of dollars in bills because someone used their keys to massively upload files.

Correct approach:

1. Keys only in server-side environment variables (.env.local), never commit to Git
2. Use IAM roles to limit permissions, only give S3 upload permission, not delete or management
3. Set Bucket lifecycle policies to auto-delete temporary files over 30 days, avoid runaway storage costs

IAM Minimum Permission Example:

阿里云 - 开发者上云首选，轻量服务器专享 8.5 折优惠，助力项目快速上线

领取 8.5 折优惠 →推广

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": ["s3:PutObject", "s3:PutObjectAcl"],
      "Resource": "arn:aws:s3:::your-bucket-name/uploads/*"
    }
  ]
}

This policy only allows uploading files to the uploads/ directory, all other operations denied.

File validation is also essential. Before server generates presigned URL, check file type and size:

// Whitelist strategy, only allow these types
const ALLOWED_TYPES = ['image/jpeg', 'image/png', 'image/webp', 'image/gif'];
const MAX_SIZE = 10 * 1024 * 1024; // 10MB

if (!ALLOWED_TYPES.includes(fileType)) {
  return NextResponse.json({ error: 'Unsupported file type' }, { status: 400 });
}

if (fileSize > MAX_SIZE) {
  return NextResponse.json({ error: 'File too large' }, { status: 400 });
}

If possible, also integrate virus scanning APIs like VirusTotal to prevent users from uploading malicious files.

Performance: Client Compression + Lazy Loading

I mentioned client-side image compression earlier, emphasizing here: in production this is mandatory, not optional.

The reason is simple: photos users take with phones are easily 5-10MB, directly uploading wastes time and traffic. Compress to under 1MB, upload speed increases 5x, storage costs drop 80%, download traffic also saved—this is a triple win.

// Recommended compression config
const compressOptions = {
  maxSizeMB: 1,
  maxWidthOrHeight: 1920,
  useWebWorker: true,
  fileType: 'image/webp', // Prefer WebP format, smaller size
};

When displaying images, use Next.js’s Image component for automatic lazy loading and responsive optimization:

import Image from 'next/image';

<Image
  src={fileUrl}
  alt="User uploaded image"
  width={800}
  height={600}
  loading="lazy"
  placeholder="blur"
/>

This way, images only load when users scroll to them, making first screen load much faster.

User Experience: Upload Queue + Resume Upload

If your app supports multiple file uploads, you need a queue manager to control concurrency. Uploading 10 images simultaneously will freeze the browser, terrible experience.

Limit concurrency:

async function uploadQueue(files: File[], maxConcurrent = 3) {
  const results = [];
  for (let i = 0; i < files.length; i += maxConcurrent) {
    const batch = files.slice(i, i + maxConcurrent);
    const batchResults = await Promise.all(batch.map(uploadFile));
    results.push(...batchResults);
  }
  return results;
}

Resume upload approach:

1. Split large files into chunks (5MB each)
2. Record progress to localStorage when uploading each chunk
3. If upload fails or user refreshes page, read progress and continue from breakpoint

S3’s Multipart Upload API natively supports chunked upload, Qiniu Cloud has similar functionality. Implementation is quite complex, here’s a reference link: AWS Multipart Upload Documentation.

Error messages should be clear:

catch (error) {
  let message = 'Upload failed, please retry';

  if (error.message.includes('NetworkError')) {
    message = 'Network unstable, please check connection';
  } else if (error.message.includes('403')) {
    message = 'Upload credential expired, please refresh page';
  } else if (error.message.includes('Too large')) {
    message = 'File too large, please select files under 10MB';
  }

  setErrorMessage(message);
}

Don’t just display “Upload failed”, tell users why it failed and how to fix it.

Monitoring: Logging + Alerts

Production environments must log for troubleshooting.

Server-side logs:

// Log when generating presigned URL
console.log(`[Upload] User: ${userId}, File: ${fileName}, Size: ${fileSize}`);

// Log detailed errors on upload failure
console.error(`[Upload Error]`, {
  user: userId,
  file: fileName,
  error: error.message,
  stack: error.stack,
});

On Vercel, these logs automatically send to their logging system. If using AWS, recommend configuring CloudWatch:

• Monitor S3 upload failure rate
• Set alerts: email notification if failure rate exceeds 5%
• Monitor Bucket storage size to avoid runaway costs

Frontend monitoring can use Sentry to auto-capture upload-related errors:

import * as Sentry from '@sentry/nextjs';

try {
  await uploadFile(file);
} catch (error) {
  Sentry.captureException(error, {
    tags: { feature: 'file-upload' },
    extra: { fileName, fileSize },
  });
  throw error;
}

This way you can see how many users encounter upload issues, which errors are most common, and optimize accordingly.

Common Issue Troubleshooting

This section lists high-frequency issues I’ve encountered, basically covering 90% of pitfalls.

Issue 1: CORS Error — “No ‘Access-Control-Allow-Origin’”

Symptoms: Browser console red error, upload request blocked.

Cause: S3 Bucket’s CORS configuration missing or incorrect. Many people forget to configure CORS after creating Bucket, browser security policy rejects cross-origin requests.

Solution:

1. Enter S3 console, select your Bucket
2. Click “Permissions” → “CORS configuration”
3. Paste this config:

[
  {
    "AllowedHeaders": ["*"],
    "AllowedMethods": ["GET", "PUT", "POST"],
    "AllowedOrigins": ["*"],
    "ExposeHeaders": ["ETag"],
    "MaxAgeSeconds": 3000
  }
]

Don’t use "*" in production, change to your actual domain like ["https://yourapp.com"].

Qiniu Cloud also needs CORS configuration, there’s a “CORS Settings” entry in Bucket settings, similar operation.

Issue 2: Presigned URL Invalid — 403 Forbidden

Symptoms: Upload returns 403 error, showing “Access Denied” or “Request has expired”.

Common causes:

1. URL expired (exceeded 60s or set time)
2. Server time not synchronized, generated signature invalid
3. IAM permissions insufficient, upload not allowed

Solutions:

• Time issue: Check if server time is correct, use date command to compare standard time, if difference exceeds 15 minutes signature becomes invalid
• Extend validity: Change expiresIn to 300 (5 minutes), give users more time
• Check permissions: Confirm IAM role includes s3:PutObject permission and Resource configured correctly

I encountered a very strange issue once: local development normal, deployed to Vercel then 403. Reason was Vercel’s serverless functions are new instances each invocation, system time might not sync. Finally solved by increasing validity period.

Issue 3: Large File Upload Timeout or Freeze

Symptoms: Upload progress bar stops at 50%, or directly times out with error.

Causes:

1. Network unstable, connection interrupted
2. File too large (e.g., 200MB video), single upload prone to failure
3. Browser or Vercel timeout limits

Solutions:

• Small files (<100MB): Implement retry logic on client

  async function uploadWithRetry(url, file, maxRetries = 3) {
    for (let i = 0; i < maxRetries; i++) {
      try {
        return await upload(url, file);
      } catch (error) {
        if (i === maxRetries - 1) throw error;
        await new Promise(resolve => setTimeout(resolve, 1000 * (i + 1)));
      }
    }
  }

• Large files (>100MB): Use Multipart Upload for chunked upload

  • Split file into multiple 5MB chunks
  • Upload individually, retry failed chunks separately
  • After all chunks upload, merge into complete file

AWS and Qiniu Cloud both have chunked upload APIs, just configuration is a bit complex, need to manage each chunk’s ETag and sequence number.

Issue 4: Upload Success But Cannot Access — 403 or 404

Symptoms: Upload returns 200, but accessing image URL shows error.

Causes:

1. Bucket permissions set to private, no public read access
2. File URL constructed incorrectly
3. CDN domain not configured or not effective

Solutions:

• S3 public access: Enter Bucket settings, turn off “Block all public access”, then add to Bucket Policy:

  {
    "Version": "2012-10-17",
    "Statement": [
      {
        "Sid": "PublicReadGetObject",
        "Effect": "Allow",
        "Principal": "*",
        "Action": "s3:GetObject",
        "Resource": "arn:aws:s3:::your-bucket-name/*"
      }
    ]
  }

• Qiniu public access: In Bucket settings select “Public Space”, after binding CDN domain files automatically accessible

• Verify URL: After upload print fileUrl, directly open in browser to test if returns image. If 404, check Bucket name, Region, file Key are correct

First time I used S3 I made this mistake: forgot to change Bucket Policy, all uploaded images couldn’t be accessed, users complained for a week before I discovered it.

Summary

After all that, the core is one sentence: Don’t let files go through your server, upload directly to cloud storage.

Presigned URL/upload token approach lets you bypass Next.js’s 4MB limit, easily support large files, zero server pressure, and good user experience. S3 and Qiniu Cloud each have their strengths—choose S3 for international products, Qiniu Cloud for Chinese market, depends on your scenario.

Technical implementation isn’t complicated, key is in details:

• Security: Don’t leak keys, IAM minimum permissions, validate file types
• Performance: Client-side compression is mandatory, saves 80% storage and traffic costs
• Experience: Progress bars, clear error messages, upload queues—these determine your product reputation
• Monitoring: Log everything, set alerts, quickly locate issues when they occur

I’ve used this solution in three production projects, running stably for over a year, handling millions of uploads. Pitfalls I encountered are basically all covered in the “Common Issues” section, following the configuration you’ll likely avoid them.

All code in the article is complete and runnable, use directly. If you encounter problems, first check CORS configuration and IAM permissions, 90% of errors are from these two causes.

Next you can try:

• Implement drag-and-drop upload (use react-dropzone)
• Add resume upload functionality (Multipart Upload)
• Support video upload and transcoding (S3 + AWS MediaConvert)
• Create a cooler progress bar upload component

File upload seems simple, doing it well isn’t easy. Hope this article helps you avoid detours and quickly build production-grade upload systems.

16 min read · Published on: Jan 7, 2026 · Modified on: Jan 15, 2026

Easton

Technology
